Granulometric Classification
CCNH
Column Classifier
Complete grain beneficiating with granulometric classification and density separation in a single equipment. 100% Brazilian technology available in three capacities — from 60 to 250 sacks per hour.
Request a Quote60 a 250 sc/h
Three models covering the entire industrial production range
Multi-stage Classification
Simultaneous separation by size and density in a column
20,83 a 71,66 HP
Scalable power according to the model capacity
National Technology
100% designed and manufactured in Brazil — Limeira, SP
← slide →
3D Model
Images
Video
Characteristics
Downloads
Orders
Models
| Model | Capacity (sc/h) | Power | Weight |
|---|---|---|---|
| CCNH-100 | 60 a 120 | 20,83 HP | 1.102 kg |
| CCNH-180 | 120 a 200 | 41,66 HP | 2.393 kg |
| CCNH-200 | 150 a 250 | 71,66 HP | 3.611 kg |
Production depends on the specific gravity of the grain. Values subject to confirmation.
Dimensions
| ID | Description | CCNH 100 | CCNH 180 | CCNH 200 |
|---|---|---|---|---|
| A | Full Length | 2320 mm | 2395 mm | 2822 mm |
| B | Full Height | 4620 mm | 5260 mm | 6715 mm |
| C | Full Width | 2720 mm | 4632 mm | 4625 mm |
